Forging Process Overview

Forging is a process of plastically forming metal by pressure. The core is to heat the blank and then use a die or forging hammer to stamp it. Relying on CNC equipment and die design capabilities, the company realizes full process control from blank forging to finishing, and cooperates with tools such as three-coordinate measuring machines to ensure accuracy and performance.

Application

Applicable to fields with high mechanical performance requirements: automotive transmission systems, hydraulic core components, agricultural machinery and industrial key components, etc. The company has passed ISO certification and customized processes to provide highly reliable and long-life metal solutions.

Forging Process Steps

Material Pretreatment
Precision Forming
Heat Treatment and Cooling
CNC Finishing
Full-process Quality Inspection

Material Pretreatment

According to the performance requirements of the parts, high-quality raw materials such as steel, aluminum alloy, and titanium alloy are selected, and the size and uniformity of the blank are ensured through cutting and heating pretreatment.
Precision Forming

After the blank is heated to the plastic temperature, the forging die developed by the company's own die design team is used, combined with the CNC four-spindle machining center and forging equipment to accurately control the punching force and deformation path to achieve one-time forming of complex structures.
Heat Treatment and Cooling

By controlling the cooling rate and heat treatment process (such as normalizing and quenching), the material grain structure is optimized, the mechanical strength and fatigue resistance are improved, and the performance requirements of high-stress components in the fields of automobiles and hydraulics are met.
CNC Finishing

After the forging blank is roughly processed by drilling machines, grinders and other equipment, the CNC vertical/horizontal machining center is used for high-precision dimensional correction and surface treatment to ensure that the tolerance range meets ISO standards.
Full-process Quality Inspection

Use three-coordinate measuring machines, projectors and other testing tools to fully verify the geometric dimensions, hardness and microstructure of finished products, combined with the ISO 9001/16949 quality system to ensure product reliability.

Through the above steps, the company realizes independent control of the entire process from blank forging to precision finished products, providing customers with high-efficiency and high-consistency customized forging solutions.

Our Forging Capabilities

Closed Die Forging

Process features: Forming in a closed cavity, no transverse flash, only a small amount of longitudinal burrs. High material utilization (up to 85%-95%), tolerance accuracy of ±0.6-0.8mm, suitable for complex precision parts such as gears and bearing rings.
Equipment adaptation: Double-acting hydraulic die frame, sliding clearance 0.08-0.20mm, die hardness HRC58-62, support friction press, hydraulic press and other equipment.
Hot Forging

Temperature range: Usually carried out above the recrystallization temperature (≥760℃), the steel is heated to about 1000℃ to reduce deformation resistance.
Advantages: Large and complex parts (such as ship crankshafts and automobile crankshafts) can be forged, but attention should be paid to the dimensional accuracy problems caused by the thickening of the oxide film.
Cold Forging

Temperature range: Carried out at room temperature (≤30℃), relying on phosphate film compound treatment technology and super-hard alloy molds.
Advantages: high dimensional accuracy (up to 0.1mm), good surface finish, suitable for batch production of small and medium-sized high-strength parts (such as automobile bolts).
Upset Forging

Process characteristics: local thickening of metal rods, and upsetting while heating through electric upsetting process, suitable for rod forgings such as valves.
Equipment: special electric upsetting machine, combined with cold-drawn materials and voltage stabilizing device, material utilization rate reaches 70%-80%.

Closed Die Forging
Hot Forging
Cold Forging
Upset Forging

Forging Production Advantages

Advantages of Professional Forging Process

The forging process improves the density of metal through plastic deformation, giving parts high strength, fatigue resistance and impact resistance. Combined with precision molding technology, it can realize one-time molding of complex structures, with a material utilization rate of 85%-95% and a dimensional accuracy of ±0.05mm, which is suitable for high-stress scenarios such as automotive transmission and hydraulic valve bodies.

Advantages of Factory auto parts forging

Advantages of This Factory Process

Relying on a four-spindle CNC machining center, its own mold design team and a three-coordinate measuring machine, it realizes independent control of the entire process from blank forging to finishing, ensures product reliability through the ISO 9001/16949 quality system, and provides customized high-precision solutions in the fields of auto parts, hydraulic parts, etc., with a life cycle extended by 20%-30% compared to the industry average.

Available Materials for Our Forging Services

Material Support

We provide precision forging services for materials such as steel (high-strength gears/valve bodies), aluminum alloys (lightweight agricultural machinery/forklift parts), titanium alloys (corrosion-resistant aviation parts), copper (conductive hydraulic joints) and tungsten steel (wear-resistant tools). Through closed die forging, CNC machining and three-coordinate testing, combined with ISO certification system, we ensure that material performance is fully released, providing highly reliable and long-life customized solutions for the automotive, hydraulic, aviation and other fields.

Optional Surface Treatments for Custom Parts

We provide a variety of surface treatment solutions, including heat treatment (optimizing material hardness and toughness), phosphating (improving corrosion resistance), spraying (enhancing wear resistance and insulation performance) and nitriding (increasing surface hardness to above HV1000). Combined with ISO 9001/16949 quality system, we provide highly reliable and long-life customized surface treatment services for automotive, hydraulic, agricultural machinery and other fields.
